F00SMB-J50P0SFW-01
Download page
SMB, Jack, 50Ω, pin, Vertical(180°), Flange, Soldering
Product Number:
F00SMB-J50P0SFW-01
Status:
Active
Category
Product Catalog
Connectors
Product System
RF Connector
Product Category
SMB
Style
Socket
Number of Positions
1Circuit
Contacts Type
pin
Orientation
Vertical(180°)
Colour
White
Electrical
Voltage(Max)
500V
Contact Resistance
10 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1000V AC r.m.s
Operating Temperature Range
-40ºC~+125ºC
Impedance
50Ω
Frequency Range (Max.)
6 GHz
VSWR
1.5 Max
Mechanical
Panel Mount Feature
Flange
Mounting Style
Soldering
Material
Material-Contact
Brass
Plating
Gold plated
Plating Thickness
0.025μm
Material-Resin
PTFE
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag
{{item.nameEn}}
{{file.fileName}} {{ file.fileName && file.fileName.startsWith('ZH_')? 'Chinese Version' : 'English Version' }}
REACH (EU REACH Regulation) Does not contain REACH SVHC (1907/2006/EC)
ROHS (EU ROHS Directive) Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2)
ELV (EU ELV Directive) Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements
The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
Quantity
Unit Price (including tax)
1+
{{5.559829 | tradeCurrencySymbol}}
20+
{{4.776595 | tradeCurrencySymbol}}
500+
{{4.639595 | tradeCurrencySymbol}}
1000+
{{4.404692 | tradeCurrencySymbol}}
5000+
{{4.287407 | tradeCurrencySymbol}}
stock 100 In stock

Immediate delivery is only the inventory quantity. If it exceeds the inventory quantity, you need to wait

MPQ: 500
MOQ: 1000

When the purchase quantity is less than the inventory, you can purchase directly, and the minimum purchase quantity is 1

When the purchase quantity is greater than the inventory, you need to order; when ordering, the purchase quantity is: MOQ + N * MPQ
