FHG25404-D04M1K6B

Download page

Wire to board Housing, 2.54mm, 4Circuits

Product Number：

FHG25404-D04M1K6B

Status：

Active

Product Introduction Data Download Product Compliance Compatible Parts

Category

Product Catalog

Connectors

Product System

Wire to Board/Wire Connector

Style

Housing

Gender

Male

Pitch

2.54mm

Row Option

Dual row

Number of Positions

4Circuits

Orientation

Vertical(180°)

Colour

Black

Electrical

Current(Max)

2.5A

Voltage(Max)

250V

Operating Temperature Range

-25ºC~+85ºC

Material

Material-Resin

PBT

Flammability Rating

UL94 V-0

Packaging

Packaging

PE Bag

{{item.nameEn}}

{{file.fileName}}

REACH (EU REACH Regulation)	Does not contain REACH SVHC (1907/2006/EC)
ROHS (EU ROHS Directive)	Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2)
ELV (EU ELV Directive)	Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements

Terminal

Wire to board terminal 2.54mm Female(Tin-Plated)

Wire to board terminal 2.54mm Female

Receptacle

FPH25452-D04S1014190740B

Pin Header 2.54mm, Double row, 4Circuits, 180° Vertical(DIP), 1μ", PA6T

FPH25461-D04B1014191107B

Pin Header 2.54mm, Double row, 4Circuits, 90° Angle(DIP), 1μ", PA6T

The pictures are for reference only for installation methods, please refer to the specifications and drawings for details

Order quantity：

Select Contact Method:

Phone

Email

Order quantity：

{{maskPhone(inquiryForm.phone)}}

{{maskEmail(inquiryForm.email)}}

The product is currently out of stock. You can leave a message on TXGA and customer service will call back according to your needs

FHG25404-D04M1K6B

Wire to board Housing, 2.54mm, 4Circuits

Order quantity：

MPQ： 1000

MOQ： 1000

When the purchase quantity is less than the inventory, you can purchase directly, and the minimum purchase quantity is 1

When the purchase quantity is greater than the inventory, you need to order; when ordering, the purchase quantity is: MOQ + N * MPQ
