FMD006-M015BDBU-00
Download page
Micro-D connector, 15Circuits, Male, Right angle(90°), Through hole, Blue (J30J-15TJWP7)
Product Number:
FMD006-M015BDBU-00
Status:
Active
Category
Product Catalog
Connectors
Product System
Micro-D Connector
Product Category
Micro-D connector
Style
Socket
Gender
Male
Pitch
1.27mm
Row Option
Dual row
Number of Positions
15Circuits
Contacts Type
pin
Orientation
Right angle(90°)
Colour
Blue
Electrical
Current(Max)
3A
Voltage(Max)
500V
Contact Resistance
10 mΩ Max
Insulation Resistance
5000 MΩ Min
Withstanding Voltage
800V AC r.m.s
Operating Temperature Range
-55ºC~+125ºC
Mechanical
Waterproof / Dustproof
No
Mounting Style
Through hole
Material
Material-Contact
Copper alloy
Plating
Gold plated
Plating Thickness
0.25μm
Material-Resin
PPS
Flammability Rating
UL94 V-0
Packaging
Packaging
Box
{{item.nameEn}}
{{file.fileName}} {{ file.tags && file.tags.indexOf('中') !== -1 ? 'Chinese Version' : 'English Version' }}
REACH (EU REACH Regulation) Does not contain REACH SVHC (1907/2006/EC)
ROHS (EU ROHS Directive) Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2)
ELV (EU ELV Directive) Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements
The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
Quantity
Unit Price (including tax)
1+
{{115.656358 | tradeCurrencySymbol}}
5+
{{112.487691 | tradeCurrencySymbol}}
10+
{{110.11119 | tradeCurrencySymbol}}
50+
{{107.73469 | tradeCurrencySymbol}}
100+
{{102.981689 | tradeCurrencySymbol}}
stock 0 Estimated delivery date {{product.leadDate|timezoneDate}}

Immediate delivery is only the inventory quantity. If it exceeds the inventory quantity, you need to wait

MPQ: 10
MOQ: 10

When the purchase quantity is less than the inventory, you can purchase directly, and the minimum purchase quantity is 1

When the purchase quantity is greater than the inventory, you need to order; when ordering, the purchase quantity is: MOQ + N * MPQ

Unit Price: {{ product.price|tradeCurrencySymbol}}
Total prices: {{ product.subTotal|tradeCurrencySymbol}}
Lead time: In stock {{product.leadDate|timezoneDate}}
The product is currently out of stock. You can leave a message on TXGA and customer service will call back according to your needs
FMD006-M015BDBU-00
Micro-D connector, 15Circuits, Male, Right angle(90°), Through hole, Blue (J30J-15TJWP7)
MPQ: 10
MOQ: 10

When the purchase quantity is less than the inventory, you can purchase directly, and the minimum purchase quantity is 1

When the purchase quantity is greater than the inventory, you need to order; when ordering, the purchase quantity is: MOQ + N * MPQ
