FTB38106-F02S2GNB

Download page

Terminal Block, 3.81mm, Plug, 2Circuits, Vertical(180°), Green

Product Number：

FTB38106-F02S2GNB

Status：

Active

Product Introduction Data Download Product Compliance Compatible Parts

Category

Product Catalog

Connectors

Product System

Terminal Block

Style

Plug

Gender

Female

Pitch

3.81mm

Number of Positions

2Circuits

Orientation

Vertical(180°)

Colour

Green

Electrical

Current(Max)

10A

Voltage(Max)

300V

Contact Resistance

20 mΩ Max

Insulation Resistance

500 MΩ Min

Withstanding Voltage

2500V AC r.m.s

Operating Temperature Range

-40ºC~+105ºC

Mechanical

Mounting Style

Screw locking

Material

Material-Contact

Phosphor bronze

Plating

Bright tin plated

Material-Resin

PA66

Flammability Rating

UL94 V-0

Packaging

Packaging

PE Bag

{{item.nameEn}}

{{file.fileName}}

REACH (EU REACH Regulation)	Does not contain REACH SVHC (1907/2006/EC)
ROHS (EU ROHS Directive)	Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2)
ELV (EU ELV Directive)	Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements

Receptacle

FTB38107-M02S2GNB

Terminal Block, 3.81mm, Socket, 2Circuits, Vertical(180°), Through hole, Green

The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
