Where you are： TXGA Products Terminal Block FTB50811 FTB50811-F12B2GNB
FTB50811-F12B2GNB
Download page
Terminal block, 5.08mm, Plug, 12Circuits, Vertical(180°), Screw locking, Green
Product Number：
FTB50811-F12B2GNB
Status：
Active
Product Introduction Data Download Product Compliance
Category
Product Catalog
Connectors
Product System
Terminal Block
Style
Plug
Gender
Female
Pitch
5.08mm
Number of Positions
12Circuits
Orientation
Vertical(180°)
Colour
Green
 Electrical
Current(Max)
15A
Voltage(Max)
300V
Contact Resistance
20 mΩ Max
Insulation Resistance
500 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+105ºC
 Mechanical
Mounting Style
Screw locking
 Material
Material-Contact
Phosphor bronze
Plating
Bright tin plated
Material-Resin
PA66
Flammability Rating
UL94 V-0
 Packaging
Packaging
PE Bag
{{item.nameEn}}
{{file.fileName}} {{ file.fileName && file.fileName.startsWith('ZH_')? 'Chinese Version' : 'English Version' }}
REACH (EU REACH Regulation) Does not contain REACH SVHC (1907/2006/EC)
ROHS (EU ROHS Directive) Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2)
ELV (EU ELV Directive) Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements
The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
Quantity
Unit Price (including tax)
1+
{{9.411351 | tradeCurrencySymbol}}
20+
{{7.656746 | tradeCurrencySymbol}}
100+
{{7.058627 | tradeCurrencySymbol}}
500+
{{6.547243 | tradeCurrencySymbol}}
1000+
{{6.023211 | tradeCurrencySymbol}}
stock 0 Estimated delivery date {{product.leadDate|timezoneDate}}

Immediate delivery is only the inventory quantity. If it exceeds the inventory quantity, you need to wait
MPQ： 100
MOQ： 500

When the purchase quantity is less than the inventory, you can purchase directly, and the minimum purchase quantity is 1

When the purchase quantity is greater than the inventory, you need to order; when ordering, the purchase quantity is: MOQ + N * MPQ
Unit Price： {{ product.price|tradeCurrencySymbol}}
Total prices： {{ product.subTotal|tradeCurrencySymbol}}
Lead time： In stock {{product.leadDate|timezoneDate}}
The product is currently out of stock. You can leave a message on TXGA and customer service will call back according to your needs
FTB50811-F12B2GNB
Terminal block, 5.08mm, Plug, 12Circuits, Vertical(180°), Screw locking, Green
MPQ： 100
MOQ： 500

When the purchase quantity is less than the inventory, you can purchase directly, and the minimum purchase quantity is 1

When the purchase quantity is greater than the inventory, you need to order; when ordering, the purchase quantity is: MOQ + N * MPQ
