The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
| Product number： | FPH254F1-D10S100128B |
| Category： | Pin Header |
| Specification： | Pitch:2.54mm |
| Type： | Plug |
| Mounting Style： | Through Hole |
| Angle： | 180°Vertical |
| Circuits： | 10Circuits |
| Status： | Inactive |
| Description： | Pin Header 2.54mm 180°Vertical Double row 10Circuits(DIP) |
| Stock(pcs)： | 0 |
| Lead time： | Estimated delivery date 2025-05-13 |
| MPQ： | 1 |
| MOQ： | 1 |
| Type： | Pin header-PCB socket Pitch：2.54mm （DIP） |
| EU RoHS： | Compliant(2011/65/EU) |
| EU REACH： | Dose not contain REACH SVHC(1907/2006/EC) |
| EU ELV： | Compliant(2000/53/EC) |
| Category | |
| Category | Pin header-PCB socket Pitch：2.54mm （DIP） |
| Pitch | 2.54mm |
| Entry Angle | 180° Vertical |
| Color - Resin | Black |
| Electrical | |
| Current - Maximum per Contact | 3.00A |
| Voltage - Maximum | 250V |
| Contact Resistance | 20 mΩ Max |
| Insulation Resistance | 1000 MΩ Min |
| Withstanding Voltage | 600V AC r.m.s |
| Temperature Range operating | -40ºC~+105ºC |
| Material and Plating | |
| Material-Metal | Brass |
| Material - Plating Mating | Gold |
| Material - Plating Termination | Gold/Tin |
| Material - Resin | PBT/PA6T UL94V-0 |
FBB25401-F Board to Board 2.54mm SMT
Type： Board to board - Female Pitch：2.54mm （SMT）
EU RoHS： Compliant(2011/65/EU)
FBB25401-M Board to Board 2.54mm SMT
Type： Board to board - Male Pitch：2.54mm （SMT）
EU RoHS： Compliant(2011/65/EU)
FBH25401 Box Header 2.54mm 180°(DIP)
Type： Box Header 2.54mm （180°DIP）
EU RoHS： Compliant(2011/65/EU)
FBH25402 Box Header 2.54mm 90°(DIP)
Type： Box Header 2.54mm （90°DIP）
EU RoHS： Compliant(2011/65/EU)
| Quantity | Unit Price |
|---|---|
| 1 | $0.113216 |
| 10 | $0.105953 |
| 50 | $0.091428 |
| 100 | $0.084165 |
| 500 | $0.069640 |
| 1000 | $0.046060 |
| 2500 | $0.045431 |
| 5000 | $0.044802 |
| 10000 | $0.044173 |
| 25000 | $0.043545 |
* Please jump to latest version page view prices for purchasing
